ENDRESS HAUSER FTL51C-DBQKBK2G4AA POINT LEVEL SWITCH

Manufacturer: ENDRESS HAUSER

Type: POINT LEVEL SWITCH

Model: LIQUIPHANT M

Order Code: FTL51CDBQKBK2G4AA

Serial No.: 62003B010E4

Electronics: FEL52

Process Pressure: -1 … +40 bar

Output: SIL 3-wire PNP 10 … 55 VDC

Load Current: max. 350 mA

Switch Point: 194 mm

Probe Length L: 207 mm

Pipe Diameter D: 24.6 mm

Min. Density of Medium: 0.5 g/cm³

Process Connection: Flanges EN1092-1 (DIN2527) , DN100 PN10/16, 316L

Probe Type: ECTFE

Cable Entry: M20 Gland

Protection: IP66/67

Process Temperature: -50 °C … +150 °C

Ambient Temperature: -50 °C … +70 °C

Weight: 7 kg

Condition: New
