THK SSR20XV1UU LINEAR GUIDE BLOCK

The THK SSR20XV1UU is a precision linear guide block designed for smooth, accurate motion in industrial automation systems. Built with high rigidity and sealed for durability, it ensures stable performance under demanding conditions.

Manufacturer: THK
Type: Linear Guide Block
Model: SSR20XV1UU

Technical Information

• Size: 20
• Length: 47.7 mm
• Width: 42 mm
• Height of Block: 22 mm
• Height of System: 28 mm
• B: 32 mm
• Dynamic Load: 13.4 kN
• Static Load: 14.4 kN
• No. of LM Block: 1
• Sealing: UU (with end seal)

Note: We also provide the corresponding rails (guideways) in a wide range of lengths – please ask us if you need rails to match your bearing.
