Siemens LOGO! 6ED10551FB100BA2 Expansion Module / Digital Input/Output Module

The Siemens LOGO! 6ED10551FB100BA2 Expansion Module is a versatile and reliable digital I/O module for automation systems. It is designed to expand the functionality of Siemens LOGO! PLC systems with 8 digital inputs and 8 relay digital outputs, providing flexible and efficient control for industrial applications.

• Manufacturer: Siemens
• Type: Expansion Module / Digital Input/Output Module
• Model Number (MNR): 6ED10551FB100BA2
• Series: LOGO!

Technical Information

• Mounting: On 35 mm DIN rail, 4 spacing units wide
• Supply Voltage: 115/230 V AC/DC
• Line Frequency: 47/63 Hz
• No. of Digital Inputs (DI): 8
• No. of Digital Outputs (DO): 8 Relay
• Switching Capacity of Contacts:
  • With inductive load, max. 3 A
  • With resistive load, max. 5 A
• Degree of Protection: IP20
• Ambient Temperature during Operation: 0 to 55°C
• Dimensions: 71.5 x 90 x 58 mm

The Siemens LOGO! 6ED10551FB100BA2 provides enhanced control in industrial and automation applications, offering high flexibility and robust performance for a wide variety of digital control tasks.
