Manufacturer: Pepperl + Fuchs
Type: Inductive Sensor
Model No.: NBB518GM50E2V1
Part No.: 84195
Rated Operating Distance: 5 mm
Assured Operating Distance: 0 … 4.05 mm
Operating Voltage: 10 … 30 V DC
Operating Current: 200 mA
Switching Frequency: 0 … 800 Hz
Electrical Design: PNP
Switching Output: Normally Open
Connector Type: M12 Connector, 3-Pin
Protection Class: II
Enclosure Rating: IP67
Ambient Operating Temperature: -40 … 70°C
Diameter, Housing Length: 18, 50 mm
Housing Material: Brass, Nickel-Plated
Sensing Face Material: PBT
Mounting: Flush-Mountable
Supplied Accessories: 2 Lock Nuts
| Model | NBB518GM50E2V1 |
|---|---|
| Part No. | 84195 |
| Condition | Used |
| Shelf No. | 220207 |
