Type: Integrated Chip
Model: TIBPAL20L815CNT
Part No.: 8296XF

Features:
• High-Performance 45 MHz Min
• Reduced ICC of 180 mA Max
• Functionally Equivalent, but Faster Than PAL20L8, PAL20R4, PAL20R6, PAL20R8
• Power-Up Clear on Registered Devices (All Register Outputs are Set Low, but Voltage Levels at the Output Pins Go High)
• Preload Capability on Output Registers Simplifies Testing
Supply voltage: 5 V
Operating voltage range: 4.75… 5.25 V
Operating Temperature: 0 … 75°C
