ABB CRP024AC2 “ Interface Relay

The ABB CRP024AC2 interface relay is a high-quality, pluggable PCB relay designed for reliable control and switching applications. With a wide range of rated operational voltages and frequencies, this relay ensures efficient operation in industrial systems.

• Manufacturer: ABB
• Type: Interface Relay
• Model: CRP024AC2
• Ref. Code: 1SVR 405 601 R0000

Technical Information:

• Function: Pluggable PCB interface relay CR-P
• Rated Control Supply Voltage (Us): 24 V AC
• Rated Operational Voltage: 400 V AC
• Rated Frequency (f): 50 / 60 Hz
• Output: 2 C/O (SPDT) contacts
• Output Signal: 250 V AC / 8 A
• Switching Rating: 240 V AC / 1 A
• Terminal Type: Soldering Pins
• Dimension: 12.7 x 15.7 x 29 mm
