Manufacturer: Abi

Type: Stainless Steel Worm Gear Motor

Model: WRSH270/MRS14d-4

Speed [r/min]: 389 / 108

Total Ratio [I]: 3.6

Rated Torque [Nm]: 35

Hollow Shaft: 20 mm

Motor Power [W]: 370

Range Voltage [V]: 400

Rated Current [A]: 0.43

Frequency [Hz]: 50

Power Factor: 0,66

Number of Pole: 4

Thermal Class: F

IEC Size: 71

Duty: Cont(S1-100%)

Protection Class [IP]: 67

Mounting Position [IM]: B5

Weight [kg]: 14.7
