Manufacturer: ACE Controls

Type: HYDRAULIC DAMPER

Model: DVC-32-50-BB-P

Compression Force: 9.5 … 300 lbs

Stroke: 50 mm

L Extended: 240 mm

Operating Temperature: 0 … 65°C

Lifetime Approx.: 250,000 cycles

Diameter Outer Body/ Piston Rod:  32 / 8 mm

Adjustment: Steplessly adjustable

Positive Stop: External positive stops 0.04 into 0.06 in before the end of stroke provided by the customer

Mounting: In any position

Material: Outer body: Coated Aluminium; Piston rod: Hard chrome plated steel; End fittings: Zinc plated steel

Damping Medium: Automatic Transmission Fluid (ATF)
