Manufacturer: ASCELL SENSOR

Type: Compression Load Cell

Model: CCI

Maximum weight limit (E max): 6000 kg

Rated Sensitivity: 2 ± 0,1 % mV/V

Rated Input Voltage: 10 V DC

Input Resistance: 700 ± 10 Ω

Output Resistance: 700 ± 10 Ω

Operating Temperature: -30…85 ºC

Cable Length: 15 m

Class: C4,5

Protection Class: IP68

Weight: 4.730 kg
