Manufacturer: AVENTICS
Type: Pneumatic Position Monitoring Device
Model: R412011545
Media: Compressed Air
Supply Voltage: 24 V DC
Detection distance (nozzle Ø 1 mm/2 mm), min./max.: 0.01, 0.3 mm
Electrical interface: M12, 5-pin
Working Pressure Max: 3.3 bar
Working Pressure Min.: 2.7 bar
Connection: Sub-based
Max. Temperature: 50°C
