BALLUFF BTL032K MAGNETOSTRICTIVE LINEAR POSITION SENSOR
The Balluff BTL032K is a high-precision magnetostrictive linear position sensor engineered for industrial automation and motion control applications. With a durable aluminum housing and IP67 protection, it performs reliably even in harsh environments. Its compact design, high resolution, and robust connector system ensure consistent and accurate positioning feedback for a variety of systems.
Manufacturer: BALLUFF
Type: Magnetostrictive Linear Position Sensor
Model: BTL032K
Part No.: BTL5E10M0250PS32
ID No.: 084843132 HU
Technical Information
- Resolution: 0.2 µA
- Rated Supply Voltage: 20 / 28 V DC
- Rated Current Consumption Max.: 150 mA
- Null Point: 73.0 mm
- Magnets No. Max.: 1
- Measuring Range: 250 mm
- Connection: Axial Connector, M16 x 0.75, 8-Pin
- Housing Material: Aluminum
- Protection Class: IP67
- Ambient Temperature: -40 / 85 °C
