NTN 6005ZZCM 5K “ Single Row Deep Groove Ball Bearing

The NTN 6005ZZCM 5K single row deep groove ball bearing is designed for high-performance applications requiring precision and durability. It features a high load capacity, low friction, and an extended temperature operating range. Ideal for a wide range of industrial uses, it ensures long-lasting performance with a grease lubrication limit of 15,000 rpm.

• Manufacturer: NTN
• Type: Single Row Deep Groove Ball Bearing
• Model: 6005ZZCM 5K

Technical Information:

• Bore Diameter (d): 25 mm
• Outer Diameter (D): 47 mm
• Width (B): 12 mm
• Min Fillet Radius (rs): 0.6 mm
• Dynamic Load Rating (Cr): 11200 N
• Static Load Rating (C0r): 5850 N
• Fatigue Load Limit: 380 N
• Grease Lubrication Limit Speed (Nlim): 15000 tr/min
• Pre-lubricant: 5K, Kyodo Yushi Multemp SRL
• Sealing: ZZ, Shielded on both sides
• Clearance: CM
• Operating Temperature: -40 to 150°C
