BI-SONIC 5E-230B AXIAL FAN

bi-sonic-5E-230B-axial-fan-new
bi-sonic-5E-230B-axial-fan-new-1
bi-sonic-5E-230B-axial-fan-new-2
bi-sonic-5E-230B-axial-fan-new
bi-sonic-5E-230B-axial-fan-new-1
bi-sonic-5E-230B-axial-fan-new-2

BI-SONIC 5E-230B AXIAL FAN

Axial Fan

BI-Sonic 5E-230B Axial Fan operates at 230 V AC with speeds of 2750 rpm and 3100 rpm, providing airflow of 339.6/407.4 m³/h and 173/197 CFM. Ideal for industrial and commercial cooling applications, featuring metal construction and ball bearing support.

SKU: 1063715 Category: Tags: , , , , , , , , , , , , , , , ,
In stock: 17 pcs
Good availability
Ready to ship from our warehouse.
Add to quote

BI-Sonic 5E-230B Axial Fan

The BI-Sonic 5E-230B Axial Fan is designed to provide efficient air circulation and cooling in various industrial and commercial applications. With a durable metal construction, it delivers reliable performance at both 2750 rpm and 3100 rpm speeds, providing optimal airflow for demanding environments.

Manufacturer: BI-Sonic

Model: 5E-230B

Type: Axial Fan

Technical Information:

  • Insulation Class: B
  • Number of Blades: 7
  • Dimension: 171x150x55 mm
  • Frame Shape: Circular Frame
  • Bearing Type: Ball Bearing
  • Airflow Direction: Push
  • Number of Wires: 2
  • Blade Material / Fan Housing Material: Metal
  • Inverter: Without
  • Nominal Voltage: 230 V AC
  • Frequency: 50/60 Hz
  • Power: 46/44 W
  • Current: 0.3/0.280 A
  • Speed: 2750/3100 rpm
  • Flow Rate: 339.6/407.4 m³/h, 173/197 CFM
Weight1,15 kg
Condition

No. of Wires

Type of Product

Inverter

Fan Housing Material

Direction

Frequency [Hz]

Blade Material

Bearing

Frame Shape

No. of Blades

Voltage [V]

Manufacturer

Shelf No.

Model

Dimensions [mm]

Current [A]

Power [kW]

Speed [RPM]

Flow Rate [m3/h]

Flow Rate CFM
