Manufacture: Cedes
Type: Safety Relay
Model: SAFECIS32P4I0
Part No.: 104 706/104 794

Features
-Short reaction times
-Extendable with up to 3 additional modules
-Simple to configure
Areas of application
-Small machines
-Rotary indexing tables
-Small presses
Supply voltage: 24 V DC
Current consumption: 70 Ma
Controller protection: 5 A slow
Response time: ≥ 5 ms
Safety outputs: 2 PNP
Interfaces: Optical
Housing material: Polyamide
Enclosure rating (housing): IP20
Ambient Operation temperature: 0 … +55 °C
Dimensions (WxHxD): 22.5 x 125 x 111 mm
