Manufacture: Cognex
Type: Bar Code Scanner
Model: DM302X
ID. No.: 825-0300-1R K
Part No.: 821-0087-3R E

Power supply: 24 V DC
Ethernet Speed: 10/100
Image Sensor: 1/1.8 inch CMOS
Image Sensor Properties: 6.9 mm x 5.5 mm (H x V); 5.3 µm square pixels (DataMan 300 and 302), 4.5 µm square pixels
Image Resolution (pixels):
-DataMan 300: 800 x 600
-DataMan 302: 1280 x 1024
-DataMan 303: 1600 x 1200
Duplex Mode: Full duplex or half duplex
Light Connector: Current load up to 630 mA average
Operating Temperature: 0 … 45°C
Protection degree: IP65
Dimensions: 83 x 44 x 112 mm
