CONTRINEX DW-AS-509-M12 INDUCTIVE PROXIMITY SENSOR
The Contrinex DW-AS-509-M12 is a high-performance inductive proximity sensor engineered for standard-duty applications requiring analog output and extended sensing capability. With a rugged chrome-plated brass housing and IP67 protection, this sensor ensures reliable performance in demanding industrial environments. Its semi-flush mounting and quick-disconnect connection make it ideal for efficient integration in automated systems.
Manufacturer: Contrinex
Type: Inductive Proximity Sensor
Model: DW-AS-509-M12
Technical Information
- Sensing Distance: 6 mm
- Operating Voltage: 10“30 VDC
- Mounting Type: Semi-flush
- Application: Standard duty and analog output
- Shape: Tubular
- Housing Size: 12 mm diameter x 60 mm body
- Barrel Type: Threaded
- Sensing Method: Extended sensing
- Analog Output: 0“5 VDC or 1“5 mA
- Connection: 4-pin M12 quick-disconnect
- Degree of Protection: IP67
- Housing Material: Chrome-plated brass
- Operating Temperature: -25 to 70°C
