Siemens SIMATIC OP77B Operator Panel

The Siemens SIMATIC OP77B Operator Panel is a reliable and compact HMI device designed for industrial automation systems. Featuring a clear backlit display, functional keys, and robust construction, it provides efficient process monitoring and control in a wide range of applications.

Manufacturer: Siemens
Type: Operator Panel
Model: 6AV6 641-0CA01-0AX0
Range: SIMATIC OP77B BACKLIT

Technical Information

• Supply Voltage: 24 V DC
• Rated Current Consumption: 0.2 A
• Screen Diagonal: 4.5 In
• Resolution: Horizontal 160 / Vertical 64 Pixel
• Memory Type: Flash / RAM, 1000 KB
• Interfaces/Bus Type: 1x RS 232, 1x RS 422, 1x RS 485 (Max. 12 Mbit/s)
• Control Elements: Membrane Keyboard
• Function Keys: 8 Function Keys, 4 with LEDs
• System Keys: 23
• Protection Class: IP20 / IP65
• Ambient Temperature: 0 / 50 °C
• Dimensions: 186 x 150 x 38.5 mm
