Merlin Gerin EGX100MG Ethernet Gateway Module

The Merlin Gerin EGX100MG Ethernet Gateway Module is a high-performance communication interface designed to integrate serial and Ethernet networks for industrial and power monitoring systems. It provides seamless data exchange between Modbus, PowerLogic, and TCP/IP devices, ensuring efficient and reliable connectivity.

Manufacturer: Merlin Gerin
Type: Ethernet Gateway Module
Model: EGX100MG
Part No.: ECU-1051TL-R10AAE
Range: PowerLogic EGX100
Short Name: EGX100

Technical Information

• Supply Voltage: 24 V DC
• Power: 4 W
• Device Connection:
• Ethernet Port FTP 10/100 Mbit/s
• Ethernet Port HTTP 10/100 Mbit/s
• Ethernet Port Modbus TCP/IP 10/100 Mbit/s
• Ethernet Port SNMP 10/100 Mbit/s
• Serial Port Modbus RTU and ASCII RS232 38400/57600 Bauds
• Serial Port Modbus RTU and ASCII RS485 38400/57600 Bauds
• Serial Port PowerLogic (SY/MAX) RS232 38400/57600 Bauds
• Serial Port PowerLogic (SY/MAX) RS485 38400/57600 Bauds
• Connection: 1 x 3-Pin Terminal Block
• Temperature: -25 / 70 °C
• Protection Class: IP30
• Dimensions: 72 x 91 x 68 mm
• Standards: AS/NZS25 60950 / IEC 60950 / EN 60950 / CSA C22.2 No. 60950 / UL 60950 / UL 508
