Manufacturer: Dold
Type: Emergency stop module
Model: BN 5983.53
Art. No.: 0031881

Width: 100 mm
Operate time: 35 ms
Thermal current Ith max.: 10 A
Power supply: 24 V AC
Frequency: 50/60 Hz
Switching capacity:
to AC 15: 5 A / AC 250 V
for NO contacts:
2 A / AC 230 V
Housing: Thermoplastic with V0 behavior according to UL subject 94
Wire connection: 2 x 2,5 mm²
Output contacts max.: 3 NO, 1 NC contacts
Degree of protection: Housing: IP 40, Terminals: IP 20
Temperature range: -15 … + 55°C
Dimensions: 100 x 74 x 121 mm
