Siemens 6SL3 040-0JA00-0AA0 Control Unit

The Siemens 6SL30400JA000AA0 is a high-performance control unit from the SINAMICS range, engineered for efficient drive and automation applications. With robust connectivity, flexible input/output options, and reliable protection, this unit is ideal for industrial environments.

Manufacturer: Siemens
Type: Control Unit
Model: 6SL3040-0JA00-0AA0
Range: SINAMICS

Technical Information

• Operating Voltage: 24 V DC
• Load Current: 0.3 A
• Digital Inputs (DI): 8
• Analog Inputs (AI): 1
• Digital Outputs (DO): 5
• Interfaces: 1 x DRIVE-CliQ, 1 x PROFIBUS, 1 x RS232
• Digital Output: 24 V DC, 0.1/0.5 A
• Protection Class: IP20
• Ambient Temperature: 0 … 55 °C
• Dimensions: 73 x 183 x 90 mm
