CONTROL TECHNIQUES / EMERSON 95UMC301CACAA BRUSHLESS AC SERVO MOTOR
This high-performance brushless AC servo motor is designed for use with Unidrive systems, offering precise speed and torque control for industrial automation applications. With advanced feedback and braking features, it delivers reliable operation across demanding environments.
Manufacturer: CONTROL TECHNIQUES / EMERSON
Type: BRUSHLESS AC SERVO MOTOR
Model: 95UMC301CACAA
MRN: 835439
Technical Information
- Frame Size: 95
- Motor Type: For Unidrive
- Stall Current: 3.7 Arms
- Voltage Constant: 98 V/Krpm
- Rated Speed: 3000 Revolution Per Minute (rpm)
- Stall Torque: 5.9 Nm
- Constant Torque: 1.6 Nm/A
- Voltage Brake: 24 VDC
- Current Brake: 0.7 A
- Torque Brake: 6 Nm
- Poles: 6
- Feedback Device: Incremental Encoder 4096 C/T
- Connection Type: Connector (Std)
