Manufacturer: Danfoss
Type: Contactor
Model: CI20

Coil voltage: 220 /230 V@50 Hz
Thermal current (Ith): 40 A
Rated power: 10 Kw@400 V
Rated current: 20 A@400 V
Rated voltage Ue: 690 V AC
Rated impulse with stand voltage Uimp: 8 kV
General use: 40 A,600 V AC
Torque: 2.8 Nm
Connection method: Screw and clamp washer
No. of poles: 3
Standard: IEC 947-4-1 / EN 60947-4-1
Operating temperature: 40 … 60°C
Dimensions: 97.1 x 112.5 x 55 mm
