Manufacturer: Dold
Type: Two-Hand Safety Relay
Model: BD5980N.02 DC24V
Part No: 0035300

Input
Nominal voltage UN: DC 24 V
Delay time for simultaneity demand: 0.5 s
Control contacts: 2 x 1 normally open contacts

Output
Nominal output voltage: AC 250 V
Frequency: Max. 1200 switching cycles / h

Contacts: 2 Normally open contacts
Operate / release time: Typ. 30 ms / typ. 30 ms
Contact type: Relay, forcibly guided

Operating Temperature: – 15 … + 55 °C
Degree of protection: Housing: IP 40, terminal plate: IP 20
Housing: Thermoplastic with V0 behaviour
Dimensions: 45 x 74 x 121 mm
