Manufacturer: DYNISCO

Type: Pressure Sensor

Model: MDA462-1/2-7C-15/46

Supply Voltage: 10 VDC

Output Signal: 3.33 mV

Pressure Range: 0 … 700 bar

Strain Resistance: 350 Ω

Leakage Resistance: 1000 MΩ at 50 VDC

Configuration: 4-arm Wheatstone bridge strain gage

Accuracy: 1.0%

Resolution: Infinite

Mounting Thread: thread 1/2″ 20 UNF 2A

Rigid Stem and Flexible Capillary: stem length 152mm (standard)

Max. Temperature: 400°C
