EBM Centrifugal Fan R2D220-AA24-18
The EBM Centrifugal Fan R2D220-AA24-18 is designed for high performance with efficient airflow. It offers reliable and durable operation in industrial environments with a plastic housing and ball bearings for smooth operation.
Manufacturer: EBM
Model: R2D220-AA24-18
Type: Centrifugal Fan
Technical Information:
- Size: 220 mm
- Insulation Class: F
- Number of Blades: 11
- Dimension: 225×64 mm
- Frame Shape: Circular Frame
- Bearing Type: Ball Bearing
- Airflow Direction: Push
- Number of Wires: 4
- Blade Material/Fan Housing Material: Plastic
- Inverter: Without Inverter
Performance at 50 Hz:
- Nominal Voltage: 400 V (Star Connection)
- Current: 0.16 A
- Input Power: 75 W
- Speed: 2550 rpm
Performance at 60 Hz:
- Nominal Voltage: 400 V (Star Connection)
- Current: 0.14 A
- Input Power: 85 W
- Speed: 2750 rpm
