Manufacturer: Ebm-Papst
Type: Centrifugal Fan
Model: G2E160-AL19-82
Motor: M2E068-GA
Phase: 1~
Impeller Material: Sheet Steel, Galvanized
Body Material: Die-Cast Aluminum
Air Flow [m3/h]: 385
Rated Voltage [V]: 230
Power Input [W]: 270
Rated Current [A]: 1.2
Frequency [Hz]: 50
Capacitor [µF]: 6
Capacitor voltage [VDB]: 400
Min. Back Pressure [IP]: 300
Rotational Speed [min-1]: 2300
Ambient Temperature [°C]: 55
Efficiency [η]: 33.0%
Protection Class [IP]: 00
Insulation Class: F
Duty: S1
Weight [kg]: 5.0
