Ebm-papst M4Q045CA0101 Fan Motor
The Ebm-papst M4Q045CA0101 is a high-performance fan motor designed for efficiency, durability, and low energy consumption. Built by one of the most trusted manufacturers in air movement technology, this motor ensures reliable operation in demanding industrial and commercial environments. Its robust design and quiet performance make it an ideal choice for HVAC systems, condensers, and cooling units.
Manufacturer: Ebm-papst
Type: Fan Motor
Model: M4Q045CA0101
Technical Information
- Rated Voltage: 230 V AC
- Frequency: 50/60 Hz
- Rated Current: 0.2 / 0.2 A
- Speed: 1300 / 1550 rpm
- Power Consumption: 31 / 30 W
- Power Output: 7 / 8 W
- Shaft Type: Single-ended output shaft
- Applications: Fans, condensers, evaporators, air curtains, HVAC, and cooling systems
- Certifications: CE, VDE compliant
- Bearing Shield Material: Die-cast aluminum
- Direction of Rotation: Counterclockwise (viewed toward rotor)
- Motor Protection: Impedance protection
- Ambient Temperature: -30 to 40°C
This fan motor provides smooth, vibration-free operation and excellent thermal performance. Its die-cast aluminum housing enhances durability, while the impedance protection ensures long life even under continuous duty cycles. Ideal for OEMs, repair replacements, and energy-efficient ventilation solutions.
