ELAN SRB-NA-R-C.43/V-24V SAFETY RELAY

safety relay

The ELAN SRB-NA-R-C.43/V-24V Safety Relay provides reliable control with a 150 mA rated current, 24 VDC rated voltage, and robust protection class for critical industrial applications.

SKU: 1018028 Category: Tags: , , , , , , , , , , , , ,
In stock: 1 pcs
Very low
Hurry! Only 1 left in stock.
Add to quote

ELAN SRB-NA-R-C.43/V-24V SAFETY RELAY

The ELAN SRB-NA-R-C.43/V-24V Safety Relay is designed for industrial applications requiring reliable safety control. It features a rated current of 150 mA and operates at a rated voltage of 24 VDC, providing robust protection and control for critical circuits.

Manufacturer: ELAN

Type: Safety Relay

Model: SRB-NA-R-C.43/V-24V

Technical Specifications

  • Rated Current: 150 mA
  • Rated Voltage: 24 VDC
  • Rated Insulation Voltage: 250 VAC
  • Contact Rating:
    • DC 13, 24V / 2A
    • AC 15, 230V / 3A
  • Protection Class: IP20 / IP40
Weight0,29 kg
