Elau SM 070-60-010-P0-45-M1-B1 Servo Motor
The Elau SM 070-60-010-P0-45-M1-B1 Servo Motor is designed for precision control and high efficiency in demanding applications. It offers a 70 mm flange size, rated speed of 6000 rpm, and robust protection class ratings for reliability in industrial systems.
Manufacturer: Elau
Model: SM 070-60-010-P0-45-M1-B1
Type: Servo Motor
Art. Nr: 19202602-010
Serial No.: 200421.1770
Technical Information:
- Flange Size: 70 mm
- Shaft Groove: P0, without feather groove
- Brake Voltage: B1, with brake 24 V DC
- Encoder: M1, SinCos multi-turn
- Rated Voltage: 400 V
- Rated Current: 6.0 A
- Rated Torque: 1.1 Nm
- Rated Speed: 6000 rpm
- Constant Torque: 0.78 Nm/A
- Nominal Power: 12 W
- Insulation Class: F
- Protection Class: IP 64/65
