Siemens 1PH7 184-7ND130CJ0 Asynchronous Motor

The Siemens 1PH7 184-7ND130CJ0 is a high-performance asynchronous motor designed for demanding industrial applications. With robust power output, precise speed control, forced cooling, and integrated encoder, it provides reliability and efficiency in automation and drive systems.

Manufacturer: Siemens
Type: Asynchronous Motor
Model: 1PH7 184-7ND130CJ0
Part No.: 041387435010001/2013
Encoder: D20-2048 SR

Technical information

• Cooling: KTY84 “ Cooling air over (forced cooling)
• Mounting: IM B35
• Voltage: 335/383/450 V
• Current: 90/89/86 A
• Power: 39/44/50 kW
• Power Factor: 0.83/0.82/0.81
• Frequency: 34/39/40 Hz
• Speed: 1000/1150 rpm
• IP Rate: 55
• Class: F
• Temperature: 40 °C
