EMBRACO EMT6152GK COMPRESSOR
The EMT6152GK compressor by Embraco is a reliable single-phase refrigeration component, engineered for optimal thermal performance in low to medium temperature commercial applications. Designed for use with R-404A refrigerant, it supports a wide evaporating temperature range and offers dependable operation under varying load conditions.
Manufacturer: Embraco
Type: Compressor
Model: EMT6152GK
Part No.: V17DBLE1
Engineering Nr.: 912FA67
Phase: 1~ Single Phase
Technical Information
- Horsepower: 1/4 Hp
- Rated Voltage: 220 to 240 V
- Displacement: 4.5 cm³
- Bore: 21.0 mm
- Stroke: 13 mm
- Nitrogen Charge: 0.2 to 0.3 kgf/cm²
- Max Condensing Pressures (Operating): 25.7 kgf/cm²
- Max Condensing Pressures (Peak): 28.7 kgf/cm²
- Evaporating Temperature Range: -20°C to 10°C
- Maximum Winding Temperature: 130°C
- Frequency: 50 Hz
- Refrigerant: R-404A
- Lubricant Charge: 180 ml
- Lubricant Type/Viscosity: ESTER / ISO22
