EMBRACO NEK6217GK COMPRESSOR
The Embraco NEK6217GK is a high-performance single-phase compressor designed for refrigeration systems using R-404A refrigerant. With durable construction and high efficiency, it supports a wide range of evaporating temperatures and is built for reliable performance under demanding conditions.
Manufacturer: Embraco
Type: Compressors
Model: NEK6217GK
Engineering Nr.: 959GA51
Phase: 1~ Single Phase
Technical Information
- Horsepower [Hp]: 3/4
- Rated Voltage [V]: 220“240
- Displacement [cm³]: 14.28
- Bore [mm]: 14.28
- Stroke [mm]: 30.157
- Start Winding Resistance [„¦]: 12
- Run Winding Resistance [„¦]: 3.34
- Max Condensing Pressure Operating [kgf/cm²]: 25.7
- Max Condensing Pressure Peak [kgf/cm²]: 28.7
- Evaporating Temperature Range [°C]: -20 to 10
- Maximum Winding Temperature [°C]: 130
- Frequency [Hz]: 50
- Refrigerant: R-404A
- Lubricant Charge [ml]: 350
- Lubricant Type/Viscosity: ESTER / ISO22
