EMBRACO NT2180GK COMPRESSOR
The Embraco NT2180GK is a robust single-phase compressor designed for low-temperature commercial refrigeration. Built for efficiency and reliability, it supports R-404A refrigerant and operates within a temperature range of -40°C to -10°C, making it ideal for freezer and cold storage systems.
Manufacturer: Embraco
Type: Compressor
Model: NT2180GK
Part No.: M18RB0KQ
Engineering Nr.: 922HA04
Phase: 1~ Single Phase
Technical Information
- Horsepower [Hp]: 1
- Rated Voltage [V]: 220 to 240
- Displacement [cm³]: 20.44
- Bore [mm]: 36.99
- Stroke [mm]: 19.03
- Range Temperature [°C]: -40 to -10
- Lubricants Type/Viscosity: ESTER / ISO22
- Frequency [Hz]: 50
- Refrigerant: R-404A
- Lubricant Charge [ml]: 450
