HEIDENHAIN ROD 426 5000 03S12-03 INCREMENTAL ENCODER

The HEIDENHAIN ROD 426 is a high-precision incremental encoder engineered for demanding industrial automation systems. With a solid shaft design, 5000 PPR resolution, and TTL signal output, it ensures reliable and accurate position feedback for high-speed motion applications.

Manufacturer: HEIDENHAIN
Type: Incremental Encoder
Model: ROD 426 5000 03S12-03
ID: 376 846-EZ
S No: 18 907 977 A

Technical Information

• Flange Design: Synchro flange
• Shaft Design: Solid shaft
• Shaft Diameter: 6 mm
• Voltage Supply: 5 VDC
• Resolution: 5000 Pulse per Revolution (PPR)
• Max. Current Consumption: 120 mA
• Signal Output: TTL (RS 422)
• Max Speed: 16000 rpm
• Max. Pulse Frequency: 300 kHz
• Protection Class: IP67 at housing, IP64 at shaft inlet (IP66 upon request)
• Max Temperature: 100 °C
