Informelec 711 HV Incremental Shaft Encoder

The Informelec 711 HV (Part No. 05A39170) is a high-performance incremental shaft encoder designed for accurate motion sensing in industrial automation. With line driver output, stainless steel shaft, and a maximum speed of 6000 RPM, it ensures precise signal generation and durability.

• Manufacturer: INFORMELEC
• Type: Incremental Shaft Encoder
• Model: 711 HV
• Part No.: 05A39170

Technical Information:

• Input Voltage (85°C): 4.75 to 28 VDC
• Input Current Max: 80 mA
• Input Ripple: 100 mV
• Output Format: Incremental “ Square wave with single channel
• Output Type: Line Driver
• Max Speed: 6000 RPM
• Shaft Material: 303 Stainless Steel
• Operating Temperature: 0 to 85°C
