Eurotherm / Schneider Electric EPOWER 2PH-2000A Power Controller
The Eurotherm / Schneider Electric EPOWER 2PH-2000A is a high-capacity, water-cooled power controller designed for demanding industrial applications. Built with advanced control modes, Modbus TCP communication, and true power feedback, it ensures precision, reliability, and efficiency in power regulation systems.
Manufacturer: Eurotherm / Schneider Electric
Type: Power Controller (2 PH)
Model: EPOWER 2PH-2000A-WC/600V/XXX/XXX/XXX/XXX/OO/ET/IO/IO/XX/XXX/XF/32ENG/LTC/XXX/XXX/QS/ENG/2000A/500V/1P/1P/TR/PA/TP/I2/SP/4A/XX//P/4A/XX/XX/XX/XX
Serial No.: PL2223003409-P1
Sales Order No.: 1026124/10
Customer Part No.: EPOWER_V0432
Customer Ref: 4000600450
Code: (PSL: O11)
Technical information
- Phase: 2PH
- Rated Current: 2000 A WC (water cooled version)
- Rated Voltage (Ue): 100 to 600 V AC ±10% to ±15% (water cooled HPower are only for 600V)
- Rated Operational Frequency: 47 to 63 Hz
- Rated Operational Current (Ie): 2000 A
- Protection Degree: IP10
- Pollution Degree: 2
- Operating Temperature: 40 °C at 1000 m
- Power Module: CAT III
- Fan Supply: None (≤ 100 A)
- Warranty: Standard
- Option: 00 Unit with options and/or quick start definition
- Communications Protocol: ET Modbus TCP
- Modules: IO optional board
- External Feedback: XF External feedback (Factory option)
- Remote Panel: 32ENG 32h8e English
- Software Option 1: LTC Load Tap Changer
- Quick Start: QS Quick start config
- Language: ENG English
- Load Current (Nominal): 2000 A
- Load Voltage (Nominal): 500 V
- Load Type: TR Transformer primary
- Firing Mode: PA Phase angle
- Feedback: TP True power
- Current Transfer Mode: I2 RMS load current squared transfer
- Analog Input 1 Function: SP Setpoint
- Analog Input 1 Type: 4A (4–20 mA)
- Analog Output Function: P Power
- Predictive Load Management Address: XX (00–63, Default 00)
- Driver: CAT II
