FAG 1208TV SELF-ALIGNING BALL BEARING

fag-1208TV-self-aligning-ball-bearing-new-carton
fag-1208TV-self-aligning-ball-bearing-new-carton-1
fag-1208TV-self-aligning-ball-bearing-new-carton
fag-1208TV-self-aligning-ball-bearing-new-carton-1

FAG 1208TV SELF-ALIGNING BALL BEARING

Self-Aligning Ball Bearing

The FAG 1208TV bearing features a 40 mm bore diameter, 80 mm outer diameter, and a PA66 reinforced cage, ensuring precision and reliability for applications requiring misalignment compensation.

SKU: 1058766 Category: Tags: , , , , , , , , , , , , , , , , , , ,
In stock: 12 pcs
Good availability
Ready to ship from our warehouse.
Add to quote

FAG 1208TV Self-Aligning Ball Bearing

The FAG 1208TV Self-Aligning Ball Bearing is designed to compensate for misalignment, making it ideal for applications requiring smooth and precise operation. With a solid glass-fiber reinforced polyamide cage, this bearing ensures durability and high performance under demanding conditions.

Manufacturer: FAG

Type: SELF-ALIGNING BALL BEARING

Model: 1208TV

Technical Information:

  • Bore Diameter (d): 40 mm
  • Outer Diameter (D): 80 mm
  • Width (B): 18 mm
  • Dynamic Load Rating (Cr): 19400 N
  • Static Load Rating (C0r): 6500 N
  • Fatigue Load Rating: 415 N
  • Limiting Speed: 10100 rpm
  • Reference Speed: 8600 rpm
  • Cage: TV, solid cage made of glass-fiber reinforced polyamide PA66
Weight0,41 kg
Condition

Manufacturer

Type of Product

Shelf No.

Model
