FAG 1211K.TV.C3 SELF-ALIGNING BALL BEARING

Self-Aligning Ball Bearing

The FAG 1211K.TV.C3 bearing features a 55 mm bore diameter, 100 mm outer diameter, tapered bore, and a polyamide cage for high-speed and misalignment compensation.

SKU: 1058772 Category: Tags: , , , , , , , , , , , , , , , , , ,
In stock: 6 pcs
Low stock
Only 6 items remaining.
Add to quote

FAG 1211K.TV.C3 Self-Aligning Ball Bearing

The FAG 1211K.TV.C3 Self-Aligning Ball Bearing is designed to accommodate misalignment and provide smooth operation in demanding applications. Featuring a tapered bore and solid polyamide cage, this bearing ensures reliability and high load capacity.

Manufacturer: FAG

Type: SELF-ALIGNING BALL BEARING

Model: 1211K.TV.C3

Technical Information:

  • Bore Diameter (d): 55 mm
  • Outer Diameter (D): 100 mm
  • Width (B): 21 mm
  • Dynamic Load Rating (Cr): 27000 N
  • Static Load Rating (C0r): 10000 N
  • Fatigue Load Rating: 630 N
  • Limiting Speed: 7700 rpm
  • Reference Speed: 6900 rpm
  • Cage: TV, solid cage made of glass-fiber reinforced polyamide PA66
  • Bore Type: K, Tapered, taper 1:12
  • Radial Internal Clearance: C3
Weight0,68 kg
