FAG 1215K.TV.C3 Self-Aligning Ball Bearing
The FAG 1215K.TV.C3 Self-Aligning Ball Bearing is engineered for high-performance applications, offering smooth operation and compensation for shaft misalignment. With a tapered bore design and a solid glass-fiber reinforced polyamide cage, this bearing is ideal for industrial machinery and equipment requiring reliability and durability.
- Manufacturer: FAG
- Type: Self-Aligning Ball Bearing
- Model: 1215K.TV.C3
Technical Information
- Bore Diameter (d): 75 mm
- Outer Diameter (D): 130 mm
- Width (B): 25 mm
- Basic Load Ratings:
- Dynamic (Cr): 39,000 N
- Static (C0r): 15,700 N
- Fatigue Load Rating: 980 N
- Speeds:
- Limiting Speed: 5,700 1/min
- Reference Speed: 5,500 1/min
- Bore Design: Tapered bore, taper 1:12
- Cage: TV, solid cage made of glass-fiber reinforced polyamide PA66
- Radial Internal Clearance: C3
