FAG 1218K.TV.C3 Self-Aligning Ball Bearing
The FAG 1218K.TV.C3 Self-Aligning Ball Bearing is designed for demanding industrial applications requiring smooth and precise rotation. With a tapered bore design, G3 accuracy, and a robust glass-fiber reinforced polyamide cage, this bearing ensures durability and reliability under dynamic and static loads.
- Manufacturer: FAG
- Type: Self-Aligning Ball Bearing
- Model: 1218K.TV.C3
Technical Information
- Bore Diameter (d): 90 mm
- Outer Diameter (D): 160 mm
- Width (B): 30 mm
- Basic Load Ratings:
- Dynamic (Cr): 57,000 N
- Static (C0r): 23,500 N
- Fatigue Load Rating: 1,330 N
- Speeds:
- Limiting Speed: 4,550 1/min
- Reference Speed: 4,850 1/min
- Bore Design: Tapered bore, taper 1:12
- Cage: TV, solid cage made of glass-fiber reinforced polyamide PA66
- Radial Internal Clearance: C3
