FAG 1310-K-TVH-C3 Self-Aligning Ball Bearing
The FAG 1310-K-TVH-C3 Self-Aligning Ball Bearing is designed for applications with shaft misalignments and dynamic load conditions. Featuring a tapered bore and a TVH solid cage made of glass-fiber reinforced polyamide (PA66), this bearing offers durability, reduced friction, and quiet operation in demanding environments.
Manufacturer: FAG
Type: Self-Aligning Ball Bearing
Model: 1310-K-TVH-C3
Technical Information:
- Bore Diameter (d): 50 mm
- Outer Diameter (D): 110 mm
- Width: 27 mm
- Dynamic Load Rating: 42,000 N
- Static Load Rating: 14,200 N
- Fatigue Load Limit: 900 N
- Limiting Speed: 6,900 1/min
- Reference Speed: 6,300 1/min
- Cage Type: TVH, solid cage made of glass-fiber reinforced polyamide PA66
- Bore Type: K, tapered bore
- Clearance Class: C3
