FAG 22209E1-K Spherical Roller Bearing with Tapered Bore
The FAG 22209E1-K is a high-quality spherical roller bearing with a tapered bore, designed for heavy-duty applications. Featuring an E1 design without a central rib and a robust sheet metal cage, it ensures long service life, high load capacity, and excellent performance in demanding environments.
Manufacturer: FAG
Type: Spherical Roller Bearing with tapered bore
Model: 22209E1-K
Technical information
- Bore Diameter (d): 45 mm
- Outer Diameter (D): 85 mm
- Width (B): 23 mm
- Basic Dynamic Load Rating, Radial: 104000 N
- Basic Static Load Rating, Radial: 99000 N
- Fatigue Load Limit, Radial: 13000 N
- Limiting Speed: 10100 rpm
- Reference Speed: 5600 rpm
- Bore Type: K, Tapered, taper 1:12
- Cage: Sheet metal cage
- Design: E1, without central rib
