Manufacturer: Schaeffler FAG

Type: Spherical Roller Bearing with tapered bore

Model: 22211 E1-K-C3

Replaces: 22211-E1-XL-K-C3, 22211E1K.C3

Dimensions:

Bore Diameter d: 55 mm

Outer diameter D: 100 mm

Width: 25 mm

Bore type: Tapered, taper 1:12

Dynamic load rating: 129000 N

Static load rating: 130000 N

Fatigue load limit: 17700 N

limiting speed: 9000 RPM

Reference speed: 4650 RPM

Radial internal clearance: Group 3 (C3)

Cage material: Sheet metal cage

Operating temperature: -30 … +200 °C
