Manufacturer: Schaeffler FAG

Type: Spherical roller bearing for vibratory applications

Model: 22312 E1-T41A

Replaces: 22312-E1-XL-T41A, 22312E1.T41A

Dimensions:

Bore Diameter d: 60 mm

Outer diameter D: 130 mm

Width: 46 mm

Dynamic load rating: 310000 N

Static load rating: 310000 N

Fatigue load limit: 29000 N

limiting speed: 5400 RPM

Reference speed: 4200 RPM

Radial internal clearance: Group 4 (C4)

Cage material: Sheet metal cage

Operating temperature: -30 … +200 °C
