FAG 3205-BD-TVH Double Row Angular Contact Ball Bearing

The FAG 3205-BD-TVH Double Row Angular Contact Ball Bearing is designed for high radial and axial load carrying capacity, featuring a contact angle of 30° for superior performance in heavy-duty applications.

Manufacturer: FAG

Type: Double Row Angular Contact Ball Bearing

Model: 3205-BD-TVH

Technical Information:

• Bore Diameter (d): 25 mm
• Outer Diameter (D): 52 mm
• Width (B): 20.6 mm
• Contact Angle: 30°
• Dynamic Load Rating (Cr): 22,000 N
• Static Load Rating (C0r): 15,200 N
• Fatigue Limit Load (Cur): 1,050 N
• Limiting Speed: 14,300 1/min
• Reference Speed: 12,500 1/min
• Cage Design: TVH, Solid cage made of glass-fiber reinforced polyamide PA66
