FAG Deep Groove Ball Bearing 6002-C-2Z-C3
The FAG 6002-C-2Z-C3 Deep Groove Ball Bearing is designed for high-performance applications, offering a high dynamic load rating and excellent durability. With a compact design and high-speed capabilities, it is ideal for various industrial uses.
Manufacturer: FAG
Model: 6002-C-2Z-C3
Type: Deep Groove Ball Bearing
Technical Information:
- Bore Diameter (d): 15 mm
- Outer Diameter (D): 32 mm
- Width (B): 9 mm
- Dynamic Load Rating (Cr): 6,300 N
- Static Load Rating (C0r): 2,850 N
- Fatigue Load Limit: 191 N
- Limiting Speed: 31,500 1/min
- Reference Speed: 23,200 1/min
- Cage: Steel sheet metal
- Sealing: 2Z, shielded on both sides
- Clearance: C3
