FAG 6005-2ZR-C3 “ Deep Groove Ball Bearing
The FAG 6005-2ZR-C3 deep groove ball bearing is engineered for high-performance applications, offering a non-contact shield design and reliable load ratings. With excellent sealing properties and a wide operating temperature range, it™s ideal for demanding industrial environments.
- Manufacturer: FAG
- Type: Deep Groove Ball Bearing
- Model: 6005-2ZR-C3
Technical Information:
- Bore Diameter (d): 25 mm
- Outer Diameter (D): 47 mm
- Width (B): 12 mm
- Dynamic Load Rating (Cr): 10,700 N
- Static Load Rating (C0r): 5,900 N
- Fatigue Load Limit: 315 N
- Limiting Speed: 18,600 1/min
- Reference Speed: 15,200 1/min
- Cage: Steel sheet metal
- Sealing: 2ZR, non-contact shield on both sides
- Clearance: C3
- Operating Temperature: -20 to 120 °C
