FAG Schaeffler 61805-2Z-HLC Deep Groove Ball Bearing
The FAG Schaeffler 61805-2Z-HLC Deep Groove Ball Bearing is designed to handle radial loads and is suitable for high-speed applications. With non-contact shields and a steel sheet metal cage, it ensures smooth and reliable performance in a variety of environments.
Manufacturer: FAG Schaeffler
Model: 61805-2Z-HLC
Type: Deep Groove Ball Bearing
Technical Information:
- Bore Diameter (d): 25 mm
- Outer Diameter (D): 37 mm
- Inner Ring Width (B): 7 mm
- Basic Dynamic Load Rating, Radial: 4,280 N
- Basic Static Load Rating, Radial: 2,940 N
- Fatigue Load Limit, Radial: 134 N
- Limiting Speed: 23,600 1/min
- Reference Speed: 13,400 1/min
- Sealing: 2Z, Non-contact shield on both sides
- Cage: Steel sheet metal
