FAG 6201-2RSR-C3 “ Deep Groove Ball Bearing
The FAG 6201-2RSR-C3 deep groove ball bearing is designed for high-speed, high-load applications. Featuring a steel sheet metal cage and double contact seals, this bearing provides exceptional performance and durability under various operating conditions.
- Manufacturer: FAG
- Type: Deep Groove Ball Bearing
- Model: 6201-2RSR-C3
Technical Information:
- Bore Diameter (d): 12 mm
- Outer Diameter (D): 32 mm
- Width (B): 10 mm
- Dynamic Load Rating (Cr): 7,300 N
- Static Load Rating (C0r): 3,100 N
- Fatigue Load Limit: 203 N
- Limiting Speed: 14,600 1/min
- Cage: Steel sheet metal
- Sealing: 2RSR, Contact seal on both sides
- Radial Internal Clearance: C3
- Operating Temperature: -20 to 100 °C
