FAG 7213B.TVP.UO Angular Contact Ball Bearing
The FAG 7213B.TVP.UO Angular Contact Ball Bearing is designed for high-performance applications where precision, durability, and high-speed performance are critical. With a 40° contact angle and robust dynamic and static load ratings, this bearing ensures efficient operation under heavy-duty conditions.
Manufacturer: FAG
Type: Angular Contact Ball Bearing
Model: 7213B.TVP.UO
Technical Information:
- Design: UO, Bearing set clearance-free in O or X arrangement
- Bore Diameter: 65 mm
- Outer Diameter: 120 mm
- Width: 23 mm
- Contact Angle: 40°
- Dynamic Load Rating (Cr): 71,000 N
- Static Load Rating (C0r): 55,000 N
- Fatigue Load Rating: 3,850 N
- Limiting Speed: 7,600 1/min
- Reference Speed: 5,700 1/min
- Cage: TVP; Solid cage made of glass-fiber reinforced polyamide PA66
